| Place of Origin: | SHEN ZHEN |
|---|---|
| Brand Name: | NobTra |
| Certification: | CE |
| Model Number: | NBTR88-S30-A |
| Minimum Order Quantity: | 1pcs |
| Price: | 285.3USD |
| Packaging Details: | Standard export carton |
| Delivery Time: | 6-8 working days for sample order |
| Payment Terms: | T/T, Paypal, L/C, In Cash, WeChat, Alipay |
| Supply Ability: | 5000pcs-7000pcs/Months |
| Radar Detection Range: | 0-500m | Warranty: | 2 Year |
|---|---|---|---|
| Operating Temperature: | -40°C To 60°C | Led Color: | Red Green |
| Material: | Iron | Display Format: | 30/40/50/60 KM/H |
| Visibility: | >300 Meters | Weatherproof: | IP54 |
| Radar Frequency: | 24.125GHZ | Install Height:: | 2.5-4 Meters |
| Working Voltage:: | 12-24VDC Or 220VAC | Setting: | By Phone App |
| Product type: | NBTR88-S30-A |
| Application: | Intersection, highway, Mountain road,Community entrance |
| Working temperature: | -40 degree to 60 degree |
| Display color: | Red, Green |
| Power consumption: | Red: 4.8 watt Green: 3.85watt |
| Installation height: | 2.5-4 meters |
| Integrated radar working frequency: | 24.125GHZ |
| Display | Vehicle speed |
| Radar Detection distance | Standard with 150 Meters |
| Phone App WIFI connect distance | Within 10 Meters |
| Application: | Used for the intersection or highway |
| Body Material: | cold-roll -steel sheets |
| LED chips: | Import from Taiwan with high brightness |
| Mounting: | With mounting bracket |
| Quality warranty: | 2 years |
| Glue Filling Process | Using the full glue filling process |
| Radar working frequency | 24.150GHZ |
| Light lifespan working time: | 1000 hours/ 3 days |
| Parameters setting | Phone App |
| Visible distance: | >300 Meters |
| PCB material | Epoxy glass cloth laminate (FR4) |
| Front speed limit panel | 30 km/40/50/60(optional) |
| 1 Carton | 1 Set |
| Carton size | 101x15x57cm |
| G/W: | 17.2KG |
| Production time: |
4-5 working day for the sample order 6-10 working day for the 10-50pcs 11-15 working day for 51-100pcs |
1. With WIFI connection.
2. Phone App setting and easy to operation.
3. 10 level sensitive can be adjustable.
4. 10 level of brightness can be choose.
5. 20,000 snap shot record for the overspeed
6. Main/Solar Power can be optional
7. Outdoor waterproof.
8. Support custom Text.
9. Millmeter-wave radar speed measurement was accurate.
10. OEM can be accpetable. If you have othere size or others requirement. Welcome to consult me.
| 1.The mobile phone APP to set parameters within 10 meters, and can supportApple,Android and Hongmeng operating systems. |
| 2.There are ten levels of sensitivity.1 is the highest sensitivity and 10 is the lowest sensitivity. |
| 3.There are ten levels of brightness.1 is the darkest and 10 is the brightest |
| 4.Imported professional traffic radar is adopted, with high-precision vehicle real-time display function, accurate and reliable speed measurement results, strong anti-drying ability and high precision |
| 5.Radar speed limit card supports customization, which are 30,40,50,60....or other customized values |
| 6.NobTra radar speed speed sign is sealed and waterproof, and can adapt to all kinds of bad weather. |
| 7.Solar power supply continuous rainy days for 7-10 working day. |
Question1: What power options are available?
Answer1: All of the radar signs can be made in either Solar Powered or AC Powered and some have the option to be Battery operated.
Question2: What is the warranty?
Question2: With 1 years quality warranty. If the accessories had broken and due to the quality problems. We will send a new parts for replacement.
Question3: Whether support the phone app and PC app operate?
Answer3: We provide the phone App and PC app and details user manual.
Question4: Do you accept the OEM?
Answer4: Yes, we have professional R&D department. Base on your actual demand, we can OEM the product for you.
Question 5: Do you provide the techical support for the product setting and installation?
Answer5: We have details instruction. If you don't know how to setting, we will send you a details operate video.
Question6: What's MOQ?
Answer6: MOQ was 1pcs
Question7: Are you a manufacturer or trading company?
Answer7: We are manufacturer of the traffic speed sign and truck mounted LED arrow board.
